D i s p l a y e d C o n t r o l P a n e l M e s s a g e s
C h a p t e r 7 : T r o u b l e s h o o t i n g ❖ 7-5
Control Panel messages are listed in alphabetical order in
Figure 7.2, preceded by numerical diagnostic error codes.
Not listed are the Control Panel menu options, settings, or
functions covered in Chapter 3: Using the Control Panel .
Some two-line messages are separated by the top line and
bottom line. In these instances, look up each line of the
message separately.
In Figure 7.2, “ACTION :” indicates what you must do to
respond to or clear the message.
Figure 7.2 Control Panel messages
Message Description/Action
0001 †
† Appears in the top left
side of the display.
Indicates which module
failed.
The main controller board has failed.
ACTION: Replace controller, or contact your dealer or Xerox / Rank Xerox.
0040 †
† Appears in the top left
side of the display.
Indicates which module
failed.
A PostScript checksum error has occurred.
ACTION: The PostScript card has failed and needs to be replaced.
0100 †
† Appears in the top left
side of the display.
Indicates which module
failed.
SIMM in slot 0 has failed.
ACTION: Move the SIMM to another slot; see “Installing a SIMM” (page 5-5) . If a
memory error (0101 or 0102) occurs again, replace the SIMM. If there is no error,
the main controller board has failed. Contact your dealer or Xerox / Rank Xerox.
0101 †
† Appears in the top left
side of the display.
Indicates which module
failed.
SIMM in slot 1 has failed.
ACTION: Move the SIMM to another slot; see “Installing a SIMM” (page 5-5) . If a
memory error (0100 or 0102) occurs again, replace the SIMM. If there is no error,
the main controller board has failed. Contact your dealer or Xerox / Rank Xerox.
Displayed
Control Panel
Messages
Note
