L o a d i n g P a p e r
2-24 ❖ 4 5 2 0 / 4 5 2 0 m p U s e r ’ s G u i d e
To feed paper into the SBF, follow the steps shown below.
When manually feeding paper in the Single-sheet Bypass
Feeder (SBF), the Multi-sheet Bypass Feeder (MBF), or the
manual tray on the High Capacity Feeder (HCF), the printer
may fail to feed the sheet if the paper is removed and then
reinserted before the feed mechanism begins to move the
sheet. The printer may indicate Online/Processing... on
the control panel. If this occurs, open and close the top cover,
reinsert the paper in the feed slot and place the printer
Online via the control panel.
1 Adjust the guides to
the desired paper size.
Make sure the guides
are snug against both
sides of the sheet but
not too tight as to
buckle it.
See Figure 2.7
(page 2-12) for SBF
information.
Feeding the SBF
Note
