L o a d i n g P a p e r
C h a p t e r 2 : H a n d l i n g P a p e r ❖ 2-29
Figure 2.15 illustrates the envelope orientation needed to
print COM-10, DL, or C5 envelopes.
Figure 2.15 Loading envelopes
1. Adjust the guides to the desired envelope size.
Make sure that they are snug against both sides of the
envelope but not too tight as to buckle it.
2. Insert only one envelope at a time into the SBF.
For best performance:
— Stand facing the SBF straight on.
— Insert the envelope (refer to Figure 2.15), guided by
the side guides, at a steady rate.
— Continue to insert the envelope until its lead edge
makes contact and a slight buckle forms. Apply
pressure first on one side of the envelope and then the
other so that the lead edge makes full contact.
— Maintain slight pressure on the envelope until the
printer begins to pull in the envelope.
To print envelopes, use the high-capacity envelope feeder
(HCEF), SBF , or MBF only.
Loading
Envelopes
Note
