P a p e r T r a y s

C h a p t e r 2 : H a n d l i n g P a p e r

❖

2-9

As shown in Figure 2.4, the 4520/4520mp printers are

packaged with three 250-sheet paper trays and one

single-sheet bypass feeder (SBF).

Figure 2.4

Input trays

Additional paper handling options are available. See

“Optional Feeders” (page 2-13)

for more information on the

multi-sheet bypass feeder (MBF), the high-capacity feeder

(HCF), and the high-capacity envelope feeder (HCEF).

Paper Trays

Single-sheet

Bypass Feeder

(SBF)

Upper Paper
Tray

Middle Paper
Tray

Lower Paper
Tray
