S e l e c t i n g a P a p e r S o u r c e
2-36 ❖ 4 5 2 0 / 4 5 2 0 m p U s e r ’ s G u i d e
Review the following Source Mapping examples to take full
advantage of the 4520/4520mp capabilities.
All examples assume that Default Source is set to Upper .
You do not have a MBF or HCF installed. You want to load as
much paper in the printer as possible. You use only one size
of paper.
1. Load the upper, middle, and lower trays with regular
paper stock.
2. Set Source Mapping for “Upper” to “Up-Mid-Low.”
3. In either your software application or the Xerox printer
driver, set paper source to the upper tray.
The printer will pull paper from the upper tray until is it
empty, then from the middle tray until it is empty, and then
from the lower tray until it is empty. As soon as the upper or
middle tray is reloaded, the printer will pull paper from them
again.
The Source Mapping setting determines from where the
printer pulls paper.
For the paper sources you intend not to use, always set Source
Mapping to the same setting as that used for your regular
paper stock. You will avoid unexpected results if those paper
sources are used by mistake.
The examples suggest using specific PCL paper sources but
generally you may substitute any source to fit your printing
needs.
Source Mapping
Examples
Example 1
Note
Note
