S e l e c t i n g a P a p e r S o u r c e
C h a p t e r 2 : H a n d l i n g P a p e r ❖ 2-35
Figure 2.18 shows the factory-set Source Mapping defaults
for the six PCL paper sources, and how the settings change
when the optional MBF, HCF, or HCEF is installed and Reset
Menus is implemented. See Chapter 3: Using the Control
Panel , “Reset Menu” (page 3-67) .
Only one of the SBF, MBF, HCF, or HCEF may be installed at
any time. Manual single-sheet feeding is possible with the
SBF, MBF, and HCF, but not the HCEF.
Install the Xerox printer driver to access the entire range of
PCL paper source and source mapping settings specifically
designed for the 4520/4520mp printers. Refer to the
Document Services for Printing Guide .
Figure 2.18 Factory settings for Source Mapping
PCL Paper
Source
Base Model With MBF With HCF With HCEF
Upper Up-Mid-Low Up-Mid-Low HCF-Up-Mid-Low Up-Mid-Low
Manual Manual MBF Manual HCEF
Manual Envelope Manual MBF Manual HCEF
Lower Lower Lower Lower Lower
Large Capacity Up-Mid-Low Up-Mid-Low HCF Up-Mid-Low
Envelope Feeder Manual MBF Manual HCEF
Factory-Set Source
Mapping Settings
Note
