I n s t a l l i n g a S I M M
C h a p t e r 5 : A d d i n g P r i n t e r O p t i o n s ❖ 5-5
Since SIMMs are widely available from manufacturers other
than Xerox and might not contain installation instructions for
the 4520/4520mp printers, installation instructions are
provided here.
The 4520 is equipped with 4 MB of resident base memory. To
expand printer memory, install up to three additional 4 MB or
16 MB SIMMs on the printer controller board.
4520mp Users:
The 4520mp is equipped with a pre-installed 4 MB SIMM for
a total of 8 MB of memory.
To install a SIMM in the 4520/4520mp, follow the steps
below:
1 Power OFF [0] the
printer.
Installing a
SIMM
Note
