Reference
AFG3000 Series Arbitrary/Function Generators Reference Manual 2-13
Save/Recall Menu The Save and Recall menus store or recall arbitrary/function generator setups. The
setups are stored in either internal setup memory or USB memory.
The arbitrary/function generator has four storage locations in non-volatile memory
to store the instrument setups. The locations are numbered 1 through 4. The instru-
ment uses location 0, which is called “last setup memory”, to overwrite the instru-
ment setups at power off.
You can select the instrument settings that are restored when you power on the
instrument. If you select Power On Last in the Utility menu, the instrument will
restore the last powered-off settings the next time you power on the instrument.
(See the Utility Menu on page 2-23.)
The Lock/Unlock menu allows you to lock the file against accidental overwrite.
When a memory location is locked, a lock icon appears on the screen.
Table 2-10: Save/Recall Menu
Save or Recall First Level Second Level Description
Save Memory
Internal
USB
Selects a memory type
(Internal or USB).
Save Saves the instrument
settings to the
specified setup
memory location.
Save As Enter Character Refer to page 2-32 for
entering a file name.
OK
Cancel
Change Directory Opens a directory.
-more- (1/2)
Lock/Unlock Locks or unlocks a file.
Erase Erases a file.
(blank)
Make Directory
Enter Character Refer to page 2-28 for
file operations.
OK
Cancel
-more- (2/2)
Recall Memory
Internal
USB
Selects a memory type
(Internal or USB).
Recall Recalls the instrument
settings from the
specified file.
(blank)
Change Directory
Opens a directory.
(blank)
