Reference
AFG3000 Series Arbitrary/Function Generators Reference Manual 2-3
Sine/Square Menu Table 2-1 shows the Sine and Square menu.
Table 2-1: Sine/Square Menu
First Level Second Level Third Level Description
Frequency/Period/
Phase Menu Frequency Selects Frequency as a
parameter to be changed.
Period Selects Period as a parameter
to be changed.
Frequency (Period)
1
CH1=CH2
Off On
1. Dual-channel model only.
Toggles between Off and On to
disable/enable the function that
sets the CH1 and CH2 to the
same value.
Phase Selects Phase as a parameter to
be changed.
Align Phase
1
Use to align the phase of two
channel signals.
Amplitude/Level Menu Amplitude Selects Amplitude as a
parameter to be changed.
Offset Selects Offset as a parameter to
be changed.
High Level Selects High Level as a
parameter to be changed.
Low Level Selects Low Level as a
parameter to be changed.
-more- (1 of 2)
Units [Vpp] Vpp
Vrms
dBm
2
2. dBm is used only for sine waveform.
Option buttons
Level
1
CH1=CH2
Off On
Toggles between Off and On to
disable/enable the function that
sets the CH1 and CH2 to the
same value.
-more- (2 of 2)
Run Mode Menu Continuous –––
Modulation Refer to Table 2-6
Sweep Refer to Table 2-7
Burst Refer to Table 2-8
Output Menu Refer to Table 2-9
