2 EMAC Functional Architecture
This section discusses the architecture and basic function of the EMAC peripheral.
2.1 Clock Control
The frequencies for the transmit and receive clocks are fixed by the IEEE 802.3 specification, as shown
below:
• 2.5 MHz at 10 Mbps
• 25 MHz at 100 Mbps
• 125 MHz at 1000 Mbps
All clock sources, with the exception of the EMAC peripheral bus clock, are sourced from the PLL2
controller. The PLL2 controller has 3 clocks for EMAC0: SYSCLK13, SYSCLK14, and SYSCLK15. For
EMAC0 operation, the SYSCLK14 divider is programmable and other clocks are fixed. The PLL multiplier
value of the PLL2 controller is also fixed. The PLL2 controller has 3 clocks for EMAC1: SYSCLK16,
SYSCLK17, and SYSCLK18. These clocks should remain fixed.
Table 3. EMAC Clock Specifications
Clock Divider Frequency Purpose
SYSCLK13 /2 250 MHz Used for RGMII0 only
/10 or 50 or 50 MHz used for RGMII (default
SYSCLK14
/4 125 MHz 125 MHz used for GMII
SYSCLK15 /100 5 MHz Used for RGMII0 only
SYSCLK16 /2 250 MHz Used for RGMII1 only
SYSCLK17 /10 50 MHz Used for RGMII1 (default)
SYSCLK18 /100 5 MHz Used for RGMII1 only
2.1.1 MII Clocking
The MII interface is supported by EMAC0 only. When MACSEL0 is set to zero (000b), the transmit and
receive clock sources are provided from an external PHY via the MTCLK and MRCLK pins. These clocks
are inputs to the EMAC module and operate at 2.5 MHz in 10-Mbps mode and at 25 MHz in 100-MHz
mode. The MII clocking interface is not used in 1000-Mbps mode. For timing purposes, data is transmitted
and received with reference to MTCLK and MRCLK, respectively.
2.1.2 RMII Clocking
The RMII interface is selected when MACSEL0 is set to 1 (001b) or MACSEL1 is set to 3 (11b). RMII
requires two clock sources, the peripheral bus clock and the reference clock (REF_CLK), input to the RMII
gasket. A 50-MHz clock from device input pin REFCLKx is supplied to the REF_CLK input of the RMII
gasket. The EMAC clocks the transmit and receive operations from the reference clock. The MTCLK and
MRCLK device pins are not used for this interface. The RMII protocol turns one data phase of an MII
transfer into two data phases at double the clock frequency. This is the driving factor for the 50-MHz
reference clock. Data at the I/O pins are running at 5 MHz in 10-Mbps mode and at 50 MHz in 100-Mbps
mode.
