13.7.14 Utility Parameters
Parameter
Function / Title Bank
Mask
Adjustment Range
Multiplier
021C
INDUSTRIAL
APPLICATIONS
(previous setting monitor
for read use only)
0 / 1
00FF
0000: Standard shipment setting
(0)
0001: Pump application
(1)
0002: Fan application
(2)
0003: Conveyor application
(3)
0004: Hoist application
(4)
0005: Textiles application
(5)
0006: Machine tools application
(6)
021D
INDUSTRIAL
APPLICATIONS
(for write use)
(*)
0 / 1
00FF
0000: Does nothing
(0)
0011: Pump application
(1)
0012: Fan application
(2)
0013: Conveyor application
(3)
0014: Hoist application
(4)
0015: Textiles application
(5)
0016: Machine tools application
(6)
021E
STANDARD SETTING
MODE SELECTION
(*)
0 / 1
00FF
0000: Does nothing
(0)
0001: 50Hz standard settings
(1)
0002: 60Hz standard settings
(2)
0003: Factory settings
(3)
0004: Trip clear
(4)
0005: Save user-set parameters
(5)
0006: TYPE 5 reset
(6)
0007: Initialize typeform
(7)
021F
COMMAND MODE
SELECTION
0 / 1
0007
0000: Only RS232C valid
(0)
0001: Terminal input valid
(1)
0002: Panel input valid
(2)
0003: Communication interface input
valid (3)
0004: local/remote valid
(4)
0220
FREQUENCY MODE
SELECTION
0 / 1
0038
0000: Only RS232C valid
(0)
0008: Terminal input valid
(1)
0010: Panel input valid
(2)
0018: Communication/12-bit binary
interface input valid
(3)
0020: local/remote valid
(4)
0221
PANEL OPERATION
MODE SELECTION
0 / 1
00FB
0000
∼ 003F (0 ∼ 63)
(except 0004, 0008, 000C....)
1
0222
PASS NUMBER
0 / 1
00FF
0000
∼ 0063 (0 ∼ 99)
1
0223
CPU VERSION
2 FFFF
(Monitor
only)
0224
ROM VERSION
3 FFFF
(Monitor
only)
0225
EEPROM VERSION
1 FFFF
(Monitor
only)
0226
INVERTER TYPEFORM
0 00FF
(Monitor
only)
0227
STATUS MONITOR #1
DISPLAY SELECT
0 / 1
FFFF
0001
∼ 0010 (1 ∼ 16)
1
0228
STATUS MONITOR #2
DISPLAY SELECT
0 / 1
FFFF
0001
∼ 0010 (1 ∼ 16)
1
0229
STATUS MONITOR #3
DISPLAY SELECT
0 / 1
FFFF
0001
∼ 0010 (1 ∼ 16)
1
022A
STATUS MONITOR #4
DISPLAY SELECT
0 / 1
FFFF
0001
∼ 0010 (1 ∼ 16)
1
022B
FREQUENCY UNITS
SCALE FACTOR
0 / 1
FFFF
0000
∼ 4E20 (0.00 ∼ 200.00)
0.01
022C
FREQUENCY DISPLAY
RESOLUTION
0 / 1
0003
0000: 1Hz
(0)
0001: 0.1Hz
(1)
0002: 0.01Hz
(2)
