70
13.7.4 Fundamental Parameters #2
Parameter Function / Title Bank Mask Adjustment Range Multiplier
0034 BASE FREQUENCY #2 0 / 1 FFFF 09C4 ∼ 9C40 (25.00 ∼ 400.00) 0.01
0035 MAXIMUM OUTPUT
VOLTAGE #2
0 / 1 FFFF 0000 ∼ 0258 (0 ∼ 600) 1
0036 VOLTAGE BOOST #2 0 / 1 FFFF 0000 ∼ 012C (0.0 ∼ 30.0) 0.1
0037 ELECTRONIC THERMAL
PROTECT LVL #2
0 / 1 00FF 000A ∼ 0064 (10 ∼ 100) 1
0038 STALL PROTECTION
SELECTION #2
0 / 1 0040 0000: ON (0)
0040: OFF (1)

0039
0
STALL PROTECTION
LEVEL #2
0 / 1 00FF 000A ∼ 00D7 (10 ∼ 215) 1
003A ACCELERATION TIME #2 0 / 1 FFFF 0001 ∼ EA60 (0.1~ 6000.0)
0001 ∼ EA60 (0.01~ 600.00)
0.1
0.01
003B DECELERATION TIME #2 0 / 1 FFFF 0001 ∼ EA60 (0.1~ 6000.0)
0001 ∼ EA60 (0.01~ 600.00)
0.1
0.01
003C ACC/DEC PATTERN #2
SELECTION
0 / 1 0030 0000: Linear (0)
0010: Self-adjusting (1)
0020: S-Pattern #1 (2)
0030: S-Pattern #2 (3)

003D ACC/DEC #1/#2 SWITCH
FREQUENCY
0 / 1 FFFF 0000 ∼ Fmax 0.01
13.7.5 Panel Control Parameters
Parameter Function / Title Bank Mask Adjustment Range Multiplier
003E DIRECTION SELECTION
(FORWARD/REV)
0 / 1 0004 0000: Reverse (0)
0004: Forward (1)

003F STOP PATTERN
SELECTION
0 / 1 0040 0000: Decelerated stop (0)
0040: Coast stop (1)

0040 FUNDAMENTAL PARAM
SWITCHING
0 / 1 0004 0000: V/F #1 (1)
0004: V/F #2 (2)

0041 ACCEL/DECEL #1/#2
SELECTION
0 / 1 0008 0000: Accel / decel #1 (1)
0008: Accel / decel #2 (2)

0042 PANEL RESET
SELECTION
0 / 1 0030 0000: All possible (0)
0010: OL only (1)
0020: OL, OC only (2)

0043 PANEL FEEDBACK
CONTROL
0 / 1 0001 0000: Feedback valid (0)
0001: Feedback invalid (1)

