E6581741
- 70 -
Response format: (ID = 251)
Byte Meaning With the IPE002Z
0 Function Code = 2Bh 2Bh
1 Type of MEI 0Eh
2 Read Device ID code 01: Basic
02: Regular
03: Extended
3 Conformity Level 2
4 More Follows 0
5 Next Object Id 0
6 Number Of Objects 3 for Basic.
6 for Regular or Extended
7 Obj 0 Id Æ Vendor Name 0
8 Obj 0 length 7
9-15 Obj 0 value “TOSHIBA”
16 Obj 1 Id Æ ProductCode 1
17 Obj 1 length 7
18-24 Obj 1 value “IPE002Z”
25 Obj 2 Id Æ Version 2
26 Obj 2 length 4
27-30 Obj 2 value “0106”
Exception response format:
Byte Meaning
0 Function Code = ABh
1
Exception Code =
01 (Illegal Function)
02 (Illegal Data Address)
03 (Illegal Data Value)
