E6581741
- 37 -
4.11. TCP/IP interface Object (0xF5)
Class code 0xF5.
The TCP/IP Interface Object provides the mechanism to configure a device’s TCP/IP network
interface.
Class Attributes
Instance Attribute ID Access Name Data type Details Value
1 Get Revision UINT Revision of this object 1
2 Get Max Instances UINT Maximum instance number of an
object currently created in this class
level of the device.
1
3 Get Number of Instances UINT Number of object instances currently
created at this class level of the
device. 1
Optional attribute list STRUCT
of List of optional instance attributes
utilized in an object class
implementation. -
Number of attributes UNIT Number of attribute in the optional
attribute list. 2
4 Get
Optional attributes ARRAY of
UINT List of optional attribute numbers. 8, 9
Optional service list STRUCT
of List of optional services utilized in
an object class implementation. -
number services UINT Number of services in the
optional service list. 0
5 Get
optional services ARRAY of
UINT List of optional service codes. -
6 Get Max ID of class
attributes UINT The attribute ID number of the last
class attribute of the class definition
implemented in the device. 7
0
7 Get Max ID of instance
attribute UINT The attribute ID number of the last
instance attribute of the class
definition implemented in the device. 9
Class Services
Service Code Service Name Description of Service
0x01 Get_Attribute_All Read all attributes
0x0E Get_Attribute_Single Read one attribute
