E6581741
- 45 -
5.1.1. Instance 20: CIP basic speed control output
Instance 20 mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 - - - - - Fault reset - Run Fwd
1 -
2
Drive Speed Reference min -1
(Low byte) *
3 Drive Speed Reference min -1
(High byte) *
5.1.2. Instance 70: CIP basic speed control input
Instance 70 mapping
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 - - - - -
Running1*
(Fwd)
- Faulted
1 -
2
Drive Actual Speed min -1
(Low byte)
3 Drive Actual Speed min -1
(High byte)
* Running1 means "Running Forward."
Examples of Instance 20/70
(1) Stop
Instance Byte 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Hex.
1, 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0x0000
Output Instance 20
3, 2 - - - - - - - - - - - - - - - - -
1, 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0x0000
Input Instance 70
3, 2 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0x0000
(2) Forward running 1800 rpm **
Instance Byte 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Hex.
1, 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0x0001
Output Instance 20
3, 2 0 0 0 0 0 1 1 1 0 0 0 0 1 0 0 0 0x0708
1, 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0x0004
Input Instance 70
3, 2 0 0 0 0 0 1 1 1 0 0 0 0 1 0 0 0 0x0708
(3) Fault reset ***
Instance Byte 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Hex.
1, 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0x0004
Output Instance 20
3, 2 - - - - - - - - - - - - - - - - -
**
Drive Reference Speed is set up number of rotations by the hexadecimal number.
For example, when "Frequency reference" is set up to 1800 min -1 :
1800 = 708H
*** Fault reset works only 1 time when 0 -> 1.
