E6581741
- 22 -
4. Objects
This section contains the object specifications for all EtherNet/IP objects currently
supported by the “IPE002Z”. Table 1 outlines those objects covered:
Class Code
Hex. Dec.
Object Class Page
0x01 1 Identity Object 23
0x02 2 Message Router Object 25
0x04 4 Assembly Object 26
0x06 6 Connection Manager Object 27
0x28 40 Motor Data Object 28
0x29 41 Control Supervisor Object 29
0x2A 42 AC/DC Drive Object 32
0x64 100 Parameter Object 33
0x65 101 Parameter Object 35
0xF4 244 Port Object 36
0xF5 245 TCP/IP Interface Object 37
0xF6 246 Ethernet Link Object 39
Table 1: Supported Objects
For definitions of all data types referred to in these object specifications, refer to the
ODVA EtherNet/IP™ Specifications. In general, however, the following are some of the
most prevalent types:
BOOL .......................... Boolean 0(False) or 1(TRUE)
SINT ............................ Signed Short Integer -128 to 127
INT .............................. Integer -32768 to 32767
DINT............................ Double Integer -2 31 to 2 31 -1
USINT ......................... Unsigned Short Integer 0 to 255
UINT............................ Unsigned Integer 0 to 65535
UDINT ......................... Unsigned Double Integer 0 to 2 32 -1
STRING ...................... character string (1 byte per character)
SHORT_STRING........ character string (1 byte per character, 1 byte length indicator)
BYTE........................... Bit string - 8-bits
WORD......................... Bit string - 16-bits
DWORD ...................... Bit string - 32-bits
EPATH ........................ CIP path segments
