6.6 Cabling for TLS-412xxx Libraries with up to twelve AIT Tape
Drives
Two separate Fibre Channel Options are necessary to connect the cables from a TLS-
412xxx with seven up to twelve AIT tape drives installed. If six or fewer AIT tape
drives are installed see Section 6.5.
Connectors on Rear of FCO Connectors on Rear of TLS-412xxx
FCO 1 SCSI Channel 2 Left Medium Changer
Left Tape Drive 1 (LT1)
Left Tape Drive 2 (LT2)
Left Tape Drive 3 (LT3)
FCO 1 SCSI Channel 1 Left Tape Drive 4 (LT4)
Left Tape Drive 5 (LT5)
Left Tape Drive 6 (LT6)
FCO 2 SCSI Channel 2 Right Tape Drive 1 (RT1)
Right Tape Drive 2 (RT2)
Right Tape Drive 3 (RT3)
FCO 2 SCSI Channel 1 Right Tape Drive 4 (RT4)
Right Tape Drive 5 (RT5)
Right Tape Drive 6 (RT6)
Table 6-5 Preferred Fibre Channel Option Cable Connections for 12 AIT Tape Drives
