Monitoring and Configuring the Printer
70
4
Displaying Top Page
This section explains the Top Page and how to display Web Image Monitor.
A
Start your Web browser.
B
Enter “http: //(machine's address)/” in the address bar of a Web browser.
Top Page of Web Image Monitor appears.
Note
❒ If the machine's host name has been registered on the DNS or WINS server,
you can enter it. For details, see p.139 “Using DHCP”.
❒ When setting SSL, a protocol for encrypted communication, under envi-
ronment which server authentification is issued , enter "https://(ma-
chine's address)/".
Every Web Image Monitor page is divided into the following areas:
1. Header area
The link to help and dialog box for
keyword search appears.
2. Menu area
The dialog box for switching to the
user mode and administrator mode
appears, and each mode's menu will
be displayed.
If you select menu, it's content will be
shown on the work area, or the sub area.
3. Display area
Displays the contents of the item se-
lected in the menu area.
Machine information in the display
area is not automatically updated.
Click [Refresh] at the upper right in the
display area to update the machine in-
formation. Click the Web browser's
[Refresh]
button to refresh the entire
browser screen.
Machine status, network interface
board names, and comments are dis-
played.
4. Help
Use Help to view or download Help
file contents.
1
3
4
4
ZZZ008S
2
