M3062PT2-EPB User’s Manual
5. Troubleshooting
REJ10J0868-0200 Rev.2.00 January 16, 2006
(3) Errors Occur at Emulator Debugger Startup
Table 5.4 Checkpoints of errors at debugger startup
Error Checkpoint
Target MCU is uncontrollable.
(1) Check that the NQPACK etc. mounted on the user system is soldered
properly.
(2) Check that the connector is installed properly to the user system.
(3) In memory expansion mode or microprocessor mode, check pins
RDY# and HOLD# are at “H” level.
