M3062PT2-EPB User’s Manual 2. Setup
REJ10J0868-0200 Rev.2.00 January 16, 2006
2.8.2 If an Error is Detected in the Self-check
If the self-check does not result normally (ERROR 1 to ERROR 4 in Figure 2.6), check the following.
(1) Recheck the connection of the emulation probe and PC7501.
(2) Redownload the proper firmware.
IMPORTANT
Note on the Self-check:
Perform the self-check while not connecting the user system.
If the self-check does not result normally (excluding user system errors), the emulation probe may be damaged.
Then contact your local distributor.
Page 29 of 102
