M3062PT2-EPB User’s Manual
3. Usage (How to Use the Emulator Debugger)
REJ10J0868-0200 Rev.2.00 January 16, 2006
(2) MAP tab
Specifying the emulation memory
allocation
Sets the memory area assigned to the emulation memory
by 4KB. Up to four areas can be set.
An area set to [INTERNAL] will be allocated to the
emulation memory by selecting the check box. An
unchecked area or an unset area will be allocated to
external area.
The setting is effective only in the CS3#, CS2#, CS1#
and CS0#. The maps of SFR, internal ROM and RAM
are set automatically.
(3) Flash Clear tab
Setting to clear the MCU’s internal flash
ROM
Specify whether or not you want the MCU’s internal
flash ROM to be cleared when downloading the user
program or data. (When cleared, the content of the flash
ROM is initialized to 0xFF.) The MCU’s internal flash
ROM is listed in block units.
- Any block which has had its check box selected is not
cleared when downloading. The memory content of
this block remains intact unless overwritten by
downloading.
- Any block which has had its check box deselected is
cleared when downloading.
- Click the Select All button, and all blocks will be
selected (marked by a check mark, so that none of the
blocks is cleared when downloading).
- Click the Clear All button, and all blocks will be
deselected (check marks removed, so that all of them
are cleared when downloading).
The option you have specified here remains effective the
next time you start up.
