M3062PT2-EPB User’s Manual 4. Hardware Specifications
REJ10J0868-0200 Rev.2.00 January 16, 2006
4.5 External Dimensions
4.5.1 External Dimensions of the Emulation Probe
Figure 4.8 shows external dimensions of the M3062PT2-EPB.
Figure 4.8 External dimensions of the emulation probe
512
100.0
60.0
15.0 15.0 55.0 15.0
5.5
10.8
16.3
34.3
10.0
9.5
21.0
9.5
10.0
Unit: mm
