M3062PT2-EPB User’s Manual
4. Hardware Specifications
REJ10J0868-0200 Rev.2.00 January 16, 2006
4. Hardware Specifications
This chapter describes specifications of this product.
4.1 Target MCU Specifications
Table 4.1 lists the specifications of target MCUs which can be debugged with this product.
Table 4.1 Specifications of target MCUs for the M3062PT2-EPB
Item Description
Applicable MCU
M16C/60 Series M16C/62P Group MCUs
M16C/30 Series M16C/30P Group MCUs
Evaluation MCU
M30627FJPGP, M30627FHPGP
ROM size : 512KB＋4KB , RAM size : 31KB
Applicable MCU mode
Single-chip mode
Memory expansion mode (NORMAL, 4MB)
Microprocessor mode (NORMAL, 4MB)
Maxi. ROM/RAM capacity
1. Internal flash ROM: 516 KB
0F000h--0FFFFh, 80000h--FFFFFh
2. Internal RAM: 31 KB
00400h--07FFFh
Power supply voltage
Vcc1＝Vcc2: 2.7--5.5[V]
Vcc1 > Vcc2: Vcc1 = 5.0 ± 0.2 V, 2.7[V] ≤ Vcc2 < Vcc1
Operating voltage/frequency
Power supply voltage 3.0--5.5V: 24MHz (when using PLL)
Power supply voltage 2.7V: 10MHz
