M3062PT2-EPB User’s Manual 4. Hardware Specifications
REJ10J0868-0200 Rev.2.00 January 16, 2006
4.5.2 External Dimensions of the M30800T-PTC
Figure 4.9 shows external dimensions of the converter board M30800T-PTC for a 100-pin LCC (included with the M3062PT2-
EPB).
Figure 4.9 External dimensions of the M30800T-PTC
1 30
31
50
CN
2
CN
1
100
81
80 51
MADE I N JAPAN
55.0
40.0
13.5
13.5
M30800T-PTC
10.8
16.3
External dimension when connecting the 100-pin LCC socket
Unit: mm
