M3062PT2-EPB User’s Manual 3. Usage (How to Use the Emulator Debugger)
REJ10J0868-0200 Rev.2.00 January 16, 2006
3.1.3 Checking Connections of the Emulator System
Checking connections of the emulator
system
When the emulator debugger is connected correctly to
the emulator after you’ve finished setting up the Init
dialog box and the MCU Setting dialog box, you will see
a message “Connected” displayed on the “Debug” tab of
the Output window.
Page 57 of 102
