M3062PT2-EPB User’s Manual
3. Usage (How to Use the Emulator Debugger)
REJ10J0868-0200 Rev.2.00 January 16, 2006
3.2 Editor (Source) Window
(1) Program window
Downloading the program
Download the object program you want to debug.
Select Download from “xxx.x30” of “Download
module”.
Or you can select “Download” from the “Debug” menu
for the same effect.
(2) Showing the program
Editor (Source) window
The editor (source) window is a window that always
shows the content of the source file corresponding to the
current position of the program counter. It automatically
opens when the emulator starts up. The program counter
position is marked by a yellow arrow. Here, you can
execute the program up to the cursor position, set or clear
software breakpoints, and line-assemble the source file.
Because this product uses the MCU’s internal flash
ROM, the initial value for the ROM area data at the time
of purchase is “FFh.”
