P APER H ANDLING 3.6
Using the Bypass Tray
Bypass Tray is located at the right side of your machine. It can
be closed when you are not using it, making the machine more
compact.
Use the Bypass Tray to print transparencies, labels, envelopes
or postcards in addition to making quick runs of paper types or
sizes that are not currently loaded in the paper Tray.
Acceptable print media are plain paper with sizes ranging from
98 x 148 mm (3.9 x 5.8 in.) to Legal 216 x 356 mm (8.5 x 14
in.), the largest size acceptable, and weighing between 16lb and
32lb.
The following table summarizes the print media allowed as well
as their stacking height limit.
Notes:
• Always load only use print media specified in Specifications to
avoid paper jams and print quality problems.
• Do not hit the Bypass Tray or rest your hands on it; otherwise
the tray may be damaged or detached from the machine.
• Flatten any curling on postcards, envelopes, and labels before
loading them into the Bypass Tray.
Paper Type Stacking Height Limit
Plain Paper 100 sheets or 9mm (max)
a
a. The height is measured with the stack of sheets untouched laid
on a flat surface.
Envelope 10 envelopes or 9mm (max)
a
Transparency 30 sheets or 9mm (max)
a
Label 30 sheets or 9mm (max)
a
Cardstock 10 sheets or 9mm (max)
a
