NEC L320 User Manual
Page 108

5-14 Using the System Drives and Bays
Removing the memory module
5.
Locate the alignment notch on the upgrade module.
6.
Locate the memory module slot.
7.
Align the notch on the module with the notch in the slot connector and install the
module as follows (see the following figure):
Before handling any internal components, discharge static
electricity from yourself and your clothing by touching a nearby unpainted metal surface.
T
Hold the memory module at a 60-degree angle and align its connector with the
slot in the system. Push the memory module into the slot.
T
Press down on the edge of the memory module until the locking tabs on the
sides snap into place, securing the module.
