Using the System Drives and Bays 5-13
2. Turn the system over and locate the screw on the memory bay cover.
Memory bay cover and screw
A – Memory Bay Cover B – Screw
3. Remove the screw and lift off the memory bay cover.
4. If you need to remove a module for the upgrade, remove it as follows (see the
following figure).
Before handling any internal components, discharge static
electricity from yourself and your clothing by touching a nearby unpainted metal surface.
T Press the locking tabs away from the sides of the module until the module
pops up at an angle.
T Pull the memory module out of the slot along the angle.
