56
2. Specification
Item Specification Remarks
Number of SATA connectors 4 internal channels SATA Signal: 7pin
Cache capacity 64 MB
PCI bus Conforming to PCI2.3
PCI connector Universal/32 bits 66 MHz
Maximum PCI bus transfer rate 266 MB/sec
Device interface Serial ATA Generation1
available
Maximum data transfer rate 150 MB/sec
RAID level 0, 1, 5, or 10
Maximum number of cards installed in
server 1
Maximum number of connectable HDDs 4 1 HDD connected per
channel
Maximum number of logical drives 8
Full-height PCI
In use of bracket 121 (width) x 180(depth) x
22 (height) mm Outer
dimension
Low-profile PCI
In use of bracket 81 (width) x 180 (depth) x
22 (height) mm
Weight About 0.09kg
Operating voltage 5V
Power consumption (max.) 5.3W 3.3V/1.044A
3.3V/0.458A(SDRAM)
1.8V/0.174A
Operating environment Temperature: 10ºC to 35ºC
Humidity: 20% to 80% Without condensation
