3-3. Logical Drive Creation Procedure
1. Start FastBuild Utility.
2. Press the [1] key on the Main Menu to activate [View Drive Assignments].
FastBuild (tm) Utility (c) xxxx-xxxx Promise Technology, Inc.
Channel:ID Drive Model Capacity (MB) Assignment
1:Mas MAXTOR 6Y080MO 80001
Extent 1 79933 Free
2:Mas MAXTOR 6Y080MO 80001
Extent 1 79933 Free
3:Mas MAXTOR 6Y080MO 80001
Extent 1 79933 Free
4:Mas MAXTOR 6Y080MO 80001
Extent 1 79933 Free
[ View Drives Assignments ]
[
↑] Up [↓] Down [ESC] Exit
[ Keys Available ]
3. Check the connection status of HDDs connected to each channel.
[Checking items]
„
Whether all HDDs connected to the disk array controller is recognized.
„
Whether the capacities of the HDDs are indicated correctly and whether all the
HDDs have the same capacity.
„
Whether every "Assignment" is set to "Free."
Notice
„
If HDDs of different capacities are connected, contact your service
representative.
„
If a new HDD or a HDD replaced for maintenance is connected and
"Assignment" is set to "LD x-x," contact your service representative.
4. After making sure that all the HDDs are indicated and connected correctly, press
the [Esc] key to return to the Main Menu.
