After completing the setting items, select HDDs used for logical drives to be
created in [Devices Assignments]. Move the cursor to a targeting HDD by using
the arrow keys "↑" and "↓" and press the [Space] key. The change of [Assignment]
from "N" to "Y" indicates that the HDD is assigned to the logical drive.
9.
After completing all the settings of the logical drive, press the [Ctrl] + [Y] keys to
save the configuration information.
10.
When [Fast Init] is set to "ON," the following message appears.
To do the fast initialization, press [Ctrl] + [Y] again. If not, press any other key
(such as [Esc]).
Fast Initialization Option has been selected.
It will erase the MBR data of the disks.
11.
Next, the following message appears. To divide HDDs by using the split function,
press the [Ctrl] +[Y] keys. To create a logical drive having the maximum capacity
without division, press any other key (such as [Esc]).
When a logical drive is created by using HDDs already divided, this message
does not appear. The whole capacity remaining is used automatically.
Press Ctrl-Y to Modify Array Capacity or press any
Other key to use maximam capacity...
12.
If you press the [Ctrl] + [Y] keys in (11) above, the following message appears.
Enter the capacity of the logical drive in MB. After the entry, press [Enter] to fix it.
Enter array capacity (in MB) here: 80000_
13.
After the creation of the logical drive, the [Define LD Menu] screen shown below
appears. To see the information on a created logical drive, move the cursor to the
targeting logical drive and press [Enter]. The [View LD Definition Menu] screen
appears. To return to the previous screen, press [Esc].
