80
Ex: Expansion of logical drive in RAID5
The figure below shows an example of adding a single 80GB HDD to a RAID5 logical drive
configured with three 80GB HDDs.
80GB 80GB 80GB
[Before execution]
Capacity = 160GB
Logical drive（RAID5）
80GB
80GB 80GB 80GB 80GB
Expand
Logical drive（RAID5）
[After execution]
Capacity = 240GB
