85
(2) Unsupported split configurations
(2-1) Configuration of logical drives in different RAID levels (1)
LD2-3
40GB
LD2-2
40GB
HDD 1
(120GB)
HDD 2
(120GB)
HDD 3
(120GB)
Disk array controller
LD2-1
40GB
LD1-1
80GB
LD1-2
80GB
LD1-3
80GB
RAID5
LD size: 160GB
RAID0
LD size: 120GB
(2-2) Configuration of logical drives in different RAID levels (2)
LD2-2
40GB
LD2-1
40GB
LD1-1
80GB
LD1-2
80GB
L
LD3-1
40GB
LD1-3
80GB
RAID5
LD size: 240GB
RAID1
LD size: 40GB LD3-2
40GB
LD1-4
80GB
HDD 1
(120GB)
HDD 2
(120GB)
HDD 3
(120GB)
Disk array controller
HDD 4
(120GB)
RAID1
LD size: 40GB
(2-3) Configuration of logical drives created by the different number of HDDs
HDD 1
(120GB)
HDD 2
(120GB)
HDD 3
(120GB)
HDD 4
(120GB)
Free
40GB
LD2-3
40GB
LD2-2
40GB
LD2-1
40GB
Disk array controller
LD1-1
80GB
LD1-2
80GB
LD1-3
80GB
RAID5
LD size: 240GB
RAID5
LD size: 80GB
LD1-4
80GB
