2-5. Delete LD

If you press [3] on the Main Menu, the [Delete LD Menu] screen shown below appears.
The screen allows you to delete logical drives.

Ex: configuration of logical drive in RAID5 by three HDDs

FastBuild (tm) Utility (c) xxxx-xxxx Promise Technology, Inc.

LD 1 RAID 5 3 159866 Functional

LD 2 ---- ---- ------ ----
LD 3 ---- ---- ------ ----
LD 4 ---- ---- ------ ----
LD 5 ---- ---- ------ ----
LD 6 ---- ---- ------ ----
LD 7 ---- ---- ------ ----
LD 8 ---- ---- ------ ----

[ Delete LD Menu ]

[

↑] Up [↓] Down [ESC] Exit [Del or Alt+D] Delete

[ Keys Available ]

Logical drive deletion procedure

Move the cursor to the logical drive to be deleted by using the arrow keys "↑" and
"↓."

Press the [Del] key or the [Alt] + [D] keys.

The following message appears. To delete the logical drive, press the [Ctrl] + [Y]
keys. To cancel the deletion, press any key (such as [Esc]).

Press Ctrl-Y to delete the data in the disk!
or press any other key to abort...
