5. Press the [2] key on the Main Menu to activate [Define LD Menu].
FastBuild (tm) Utility (c) xxxx-xxxx Promise Technology, Inc.
LD No RAID Mode Total Drv Capacity (MB) Status
LD 1 ---- ---- ------ ----
LD 2 ---- ---- ------ ----
LD 3 ---- ---- ------ ----
LD 4 ---- ---- ------ ----
LD 5 ---- ---- ------ ----
LD 6 ---- ---- ------ ----
LD 7 ---- ---- ------ ----
LD 8 ---- ---- ------ ----
[ Define LD Menu ]
[
↑] Up [↓] Down [ESC] Exit [Enter] Select
[ Keys Available ]
6. Put the cursor on "LD No" to be created by using the arrow keys "↑" and "↓" and
press [Enter]. Then the [Define LD Menu] screen appears. In general, select "LD
No" in the ascending order from "LD 1.".
FastBuild (tm) Utility (c) xxxx-xxxx Promise Technology, Inc.
LD No RAID Mode Total Drv
LD 1 RAID 5 0
Stripe Block: 64 KB Fast Init: OFF
Gigabyte Boundary: OFF Cache Mode: AutoSwitch
[ Define LD Menu ]
[
↑] Up [↓] Down [ESC] Exit [Space] Change Option [Ctrl-Y] Save
[ Keys Available ]
Channel:ID Drive Model Capacity (MB) Assignment
1:Mas MAXTOR 6Y080MO 80001 N
2:Mas MAXTOR 6Y080MO 80001 N
3:Mas MAXTOR 6Y080MO 80001 N
4:Mas MAXTOR 6Y080MO 80001 N
[ Drives Assignments ]
