Mediant 2000 SIP User’s Manual K. RADIUS Billing and VXML Calling Card Application
Version 4.4 251 July 2005
• RADIUSAuthServerIP
• RADIUSAuthPort
• RADIUSAccServerIP
• RADIUSAccPort
• AAAIndications
• RADIUSAccountingType
K.7 Supported RADIUS Attributes
Use Table K-3 below for explanations on the RADIUS attributes contained in the communication
packets transmitted between the Mediant 2000 and a RADIUS Server.
Table K-3: Supported RADIUS Attributes (continues on pages 251 to 252)
Attribute
Number
Attribute Name
VSA
No.
Purpose
Value
Format
Sample
AAA
2
Request Attributes
1 User-Name
Account number or calling
party number or blank
String up to
15 digits
long
5421385747
Start Acc
Stop Acc
Authe
Autho
2 User-Password User password
Up to 15
digits
Autho
4 NAS-IP-Address
IP address of the requesting
Mediant 2000
Numeric
192.168.14.4
3
Start Acc
Stop Acc
Authe
Autho
6 Service-Type Type of service requested Numeric 1: login
Start Acc
Stop Acc
26
h323-incoming-
conf-id
1 H.323/SIP call identifier
Up to 32
octets
Start Acc
Stop Acc
26
h323-remote-
address
23
IP address of the remote
gateway
Numeric Stop Acc
26 h323-conf-id 24 H.323/SIP call identifier
Up to 32
octets
Start Acc
Stop Acc
Authe
Autho
26 h323-setup-time 25 Setup time in NTP format 1 String
Start Acc
Stop Acc
26 h323-call-origin 26
The call’s originator:
Answering (IP) or Originator
(PSTN)
String
Answer,
Originate etc Start Acc
Stop Acc
26 h323-call-type 27
Protocol type or family used
on this leg of the call
String VoIP
Start Acc
Stop Acc
26
h323-connect-
time
28 Connect time in NTP format String Stop Acc
26
h323-disconnect-
time
29
Disconnect time in NTP
format
String Stop Acc
26
h323-disconnect-
cause
30
Q.931 disconnect cause
code
Numeric Stop Acc
2
The values in column ‘AAA’ are as follows:
’Start Acc’ - Start Accounting
’Stop Acc’ - Stop Accounting
’Authe’ - Authentication
’Autho’ - Authorization
