Mediant 2000 SIP
Mediant 2000 SIP User’s Manual 110 Document #: LTRT-72504
Table 6-3: SIP Configuration Parameters (continues on pages 100 to 110)
ini File Field Name
Web Parameter Name
*
Valid Range and Description
IPProfile_ID
[IP Profile Settings] IPProfile_ =
,,,,,
,,*>,,
Preference = (1-10) The preference option is used to determine the priority of the
Profile. If both IP and Tel profiles apply to the same call, the coders and other common
parameters of the preferred Profile are applied to that call. If the Preference of the Tel
and IP Profiles is identical, the Tel Profile parameters are applied.
For example:
IPProfile_1 = name1,2,1,0,10,13,15,44,1,1
IPProfile_2 = name2,$$,$$,$$,$,$$,$$,$$,$$,1
$$ = Not configured, the default value of the parameter is used.
(*) = Common parameter used in both IP and Tel profiles.
Note 1:
The IP ProfileID can be used in the Tel2IP and IP2Tel routing tables (Prefix and
PSTNPrefix parameters).
Note 2:
‘Profile Name’ assigned to a ProfileID, enabling User’s to identify it intuitively
and easily.
Note 3: This parameter can appear up to 4 times.
TelProfile_ID
[Tel Profile Settings] TelProfile_ =
,,,,,
,,,,,
, ,
Preference = (1-10) The preference option is used to determine the priority of the
Profile. If both IP and Tel profiles apply to the same call, the coders and other common
parameters of the preferred Profile are applied to that call. If the Preference of the Tel
and IP Profiles is identical, the Tel Profile parameters are applied.
For examples:
TelProfile_1 = FaxProfile,1,2,0,10,5,22,33,2,22,34,1,1
TelProfile_2 = ModemProfile,0,10,13,$$,$$,$$,$$,$$,0,$$,0,1
$$ = Not configured, the default value of the parameter is used.
(*) = Common parameter used in both IP and Tel profiles.
Note 1:
The Tel ProfileID can be used in the Trunk Group table (TrunkGroup_x
parameter).
Note 2:
‘Profile Name’ assigned to a ProfileID, enabling User’s to identify it intuitively
and easily.
Note 3: This parameter can appear up to 4 times.
