Mediant 2000 SIP User’s Manual 12. Selected Technical Specifications
Version 4.4 185 July 2005
Table 12-1: Mediant 2000 Selected Technical Specifications (continues on pages 183 to 185)
Function Specification
Environmental (AC) Operation Temp: 0° to 40° C / 32° to 104° F
Storage: -40° to 70° C / -40° to 158° F
Humidity: 10 to 90% non-condensing
Hot Swap cPCI cards are full hot swap supported
Power supplies are redundant but not hot swappable
Enclosure Dimensions 445 x 44 x 300 mm; 17.5 x 1.75 x 12 inch.
Installation 1U 19-inch 2-slot cPCI chassis, Rack mount, shelf or desk top.
Rack mount with 2 side brackets, option 2 extra (rear) side brackets.
Type Approvals
Telecommunication
Standards IC CS03; FCC part 68
Chassis and Host telecom card are approved to the following telecom standards: IC
CS03; FCC part 68; CTR 4, CTR 12 & CTR 13; JATE; Anatel, Mexico Telecom, Russia
CCC, ASIF S016, ASIF S038.
Safety and EMC Standards UL 60 950-1, FCC part 15 Class B, (Class A with Sun 2080 CPU card)
CE Mark (EN 55022 Class B (Class A with Sun 2080 CPU card), EN 60950-1, EN
55024, EN 300 386), TS001
Environmental NEBS Level 3: GR-63-Core, GR-1089-Core, Type 1 & 3. Approved for DC powered
version.
Complies with ETS 301019; ETS 300019-1, -2, -3. (T 1.1, T 2.3, T3.2). Approved for
AudioCodes or DC powered versions.
Diagnostics
Front panel Status LEDs E1/T1 status
LAN status
Gateway status (Fail, ACT, Power, and Swap Ready).
Syslog events Supported by Syslog Server, per RFC 3164 IETF standard.
SNMP MIBs and Traps SNMP v2c
All specifications in this document are subject to change without prior notice.
