Mediant 2000 SIP
Mediant 2000 SIP User’s Manual 210 Document #: LTRT-72504
6. To save the image to flash memory so it is available after a power fail, refer to Section 5.12
on page 84 .
The new background appears on all Web Interface screens.
Tip 1: If you encounter any problem during the loading of the files, or you want to
restore the default images, click the Restore Default Images button.
Tip 2: When replacing both the background image and the logo image, first load the
logo image followed by the background image.
To replace the background image via the ini file, take these 2 steps:
1. Place your background image file in the same folder as where the device’s ini file is located
(i.e., the same location defined in the BootP/TFTP configuration utility). For detailed
information on the BootP/TFTP, refer to
Appendix B on page 189 .
2. Add/modify the ini file parameters in Table F-3 according to the procedure described in
Section 6.2 on page 87 .
Note that loading the device’s ini file via the ‘Configuration File’ screen in the Web Interface
doesn’t load the logo image file as well.
Table F-3: Customizable Logo ini File Parameters
Parameter Description
BkgImageFileName The name (and path) of the file containing the new background.
Use a gif, jpg or jpeg image file.
The default is AudioCodes background file.
Note:
The length of the name of the image file is limited to 47 characters.
F.3 Customizing the Product Name
The Product Name text string can be modified according to OEMs specific requirements.
• To replace AudioCodes’ default product name with a text string via the Web Interface, modify
the two ini file parameters in
Table F-4 according to the procedure described in Section F.4
on page 211 .
• To replace AudioCodes’ default product name with a text string via the ini file, add/modify the
two ini file parameters in
Table F-4 according to the procedure described in Section 6.2 on
page 87 .
Table F-4: Web Appearance Customizable ini File Parameters
Parameter Description
UseProductName 0 = Don’t change the product name (default).
1 = Enable product name change.
UserProductName Text string that replaces the product name.
The default is “Mediant 2000”.
The string can be up to 29 characters.
