Mediant 2000 SIP User’s Manual J. SS7 Tunneling
Version 4.4 241 July 2005
Figure J-5: SS7 MTP2 Tunneling ini File Example - SG
SS7_LINK_TABLE 1 = new_link_1, 0, 2, 1,1, 2, 12, 12;
SS7_LINK_TABLE 2 = new_link_2, 0, 2, 1, 1, 4, 7,18;
SS7_LINK_TABLE 3 = new_link_3, 0, 2, 1, 1, 5, 3,1;
[\SS7_LINK_TABLE]
[ SS7_SIG_IF_GROUP_TABLE ]
FORMAT SS7_SIG_IF_GR_INDEX = SS7_IF_GR_ID,SS7_SIG_SG_MGC, SS7_SIG_LAYER, SS7_SIG_TRAF_MODE,
SS7_SIG_T_REC, SS7_SIG_T_ACK, SS7_SIG_T_HB, SS7_SIG_MIN_ASP, SS7_SIG_BEHAVIOUR,
SS7_LOCAL_SCTP_PORT, SS7_SIG_NETWORK;
SS7_SIG_IF_GROUP_TABLE 4 = 4,83, 2, 1, 2000, 2000, 30000, 1, 0, 2904, 1;
[ \SS7_SIG_IF_GROUP_TABLE ]
[ SS7_SIG_INT_ID_TABLE ]
FORMAT SS7_SIG_IF_ID_INDEX = SS7_SIG_IF_ID_VALUE, SS7_SIG_IF_ID_NAME, SS7_SIG_IF_ID_OWNER_GROUP,
SS7_SIG_IF_ID_LAYER, SS7_SIG_IF_ID_NAI, SS7_SIG_M3UA_SPC;
SS7_SIG_INT_ID_TABLE 7 = 50, BELFAST12, 4, 2, 0, 0;
SS7_SIG_INT_ID_TABLE 8 = 12, AMSTERDAM, 4, 2, 1, 0;
SS7_SIG_INT_ID_TABLE 9 = 18, ROTERDAM , 4, 2, 2, 0;
SS7_SIG_INT_ID_TABLE 10 = 1, GAUDA , 4, 2, 3, 0;
[ \SS7_SIG_INT_ID_TABLE ]
J.6 ini File Parameters in a Table Format
Tables of Parameter Values group related parameters of a specific entity and handle them
together. Tables are composed of lines and columns. The columns represent parameters types,
while each line represents an entity. The parameters in each line are called the line attributes.
Lines in table may represent (for example) a trunk, SS7 Link, list of timers for a given application,
etc.
Table J-5 and Table J-6 below provide useful examples for reference.
Note: Table J-5 and Table J-6 are provided as examples for the purpose of
illustration only and are NOT actually implemented in AudioCodes products.
