Mediant 2000 SIP User’s Manual
8. Gateway Capabilities Description
Version 4.4
139
July 2005
8
Gateway Capabilities Description
8.1
Proxy or Registrar Registration Example
REGISTER sip:servername SIP/2.0
VIA: SIP/2.0/UDP 212.179.22.229;branch=z9hG4bRaC7AU234
From:
To:
Seq: 1 REGISTER
Expires: 3600
Contact: sip:[email protected]
Content-Length: 0
The "
servername
" string is defined according to the following rules:
•
The "
servername
" is equal to "RegistrarName" if configured. The "RegistrarName" can be
any string.
•
Otherwise, the "
servername
" is equal to "RegistrarIP" (either FQDN or numerical IP
address), if configured.
•
Otherwise the "
servername
" is equal to "ProxyName" if configured.
The "ProxyName" can be
any string.
•
Otherwise the "
servername
" is equal to "ProxyIP" (either FQDN or numerical IP address).
The parameter ‘GWRegistrationName’ can be any string. If the parameter is not defined, the
parameter ‘UserName’ is used instead.
The
"sipgatewayname"
parameter (defined in the ini file or set from the Web browser)
,
can be
any string. Some Proxy servers require that the
"sipgatewayname"
(in Register messages) is
set equal to the Registrar / Proxy IP address or to the Registrar / Proxy domain name.
The Register message is sent to the Registrar’s IP address (if configured) or to the Proxy’s IP
address. The message is sent once per gateway. The registration request is resent according to
the parameter ‘RegistrartionTimeDivider’. For example, if ‘RegistrationTimeDivider = 70’ (%) and
Registration Expires time = 3600, the gateway resends its registration request after 3600 x 70% =
2520 sec. The default value of ‘RegistrartionTimeDivider’ is 50%.
8.2
Redirect Number and Calling Name (Display)
The following tables define the Mediant 2000 redirect number and calling name (Display) support
for various PRI variants:
Table
8-1: Calling Name (Display)
DMS-100
NI-2
4/5ESS
Euro ISDN
NT
TE
Yes Yes No Yes
TE
NT
Yes Yes No No
Table
8-2: Redirect Number
DMS-100
NI-2
4/5ESS
Euro ISDN
NT
TE
Yes Yes Yes Yes
TE
NT
Yes Yes Yes No
