Using the BayStack 450 10/100/1000 Series Switch
1-60 302401-D Rev 00
Trunk Configuration Screen Examples
This section shows examples of the MultiLink Trunk configuration screens for the
client/server configuration example shown in
Figure 1-40 on page 1-59 . The
screens show how you could set up the trunk configuration screens for switches
S1 to S4. See “
Spanning Tree Considerations for MultiLink Trunks ” on
page 1-72 , and “MultiLink Trunk Configuration” on page 3-37 for more
information.
Trunk Configuration Screen for Switch S1
Switch S1 is set up with five trunk configurations: T1, T2, T3, T4, and T5.
Setting up the Trunk Configuration For S1:
To set up the trunk configuration, choose MultiLink Trunk Configuration
(or press t) from the MultiLink Trunk Configuration Menu screen (
Figure 1-41 ).
Figure 1-41. Choosing the MultiLink Trunk Configuration Screen
MultiLink Trunk Configuration Menu
MultiLink Trunk Configuration...
MultiLink Trunk Utilization...
Return to Switch Configuration Menu
Use arrow keys to highlight option, press or to select option.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
