Using the Console Interface
302401-D Rev 00 3-23
Figure 3-8. VLAN Configuration Menu Screen
Table 3-7 describes the VLAN Configuration Menu screen options.
Table 3-7. VLAN Configuration Menu Screen Options
Option Description
VLAN Configuration... Displays the VLAN Configuration screen (see “VLAN Configuration ” on
page 3-24 ). This screen allows you to set up VLAN workgroups.
VLAN Port
Configuration... Displays the VLAN Port Configuration screen (see “VLAN Port Configuration ”
on page 3-26 ). This screen allows you to set up a specific switch port or all
switch ports.
VLAN Display by Port... Displays the VLAN Display by Port screen (see “VLAN Display by Port ” on
page 3-29 ).
Traffic Class
Configuration... Displays the Traffic Class Configuration screen (see “Traffic Class
Configuration ” on page 3-30 ).
Return to Switch
Configuration Menu Exits the VLAN Configuration Menu screen and displays the Switch
Configuration Menu screen.
VLAN Configuration Menu
VLAN Configuration...
VLAN Port Configuration...
VLAN Display by Port...
Traffic Class Configuration...
Return to Switch Configuration Menu
Use arrow keys to highlight option, press or to select option.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
