Using the Console Interface
302401-D Rev 00 3-31
Figure 3-12. Traffic Class Configuration Screen
Table 3-11 describes the Traffic Class Configuration screen fields.
Table 3-11. Traffic Class Configuration Screen Fields
Field Description
User Priority Column header for the read-only fields that indicate the user-priority values
from priority 0 to priority 7. These values are derived from the three-bit field in
the header of 802.1Q tagged frames (see
“IEEE 802.1Q Tagging ” on
page 1-33 ).
Traffic Class Column header for the eight user-configurable fields that correspond to the
adjacent user priority levels.
Default Low
Range Low, High
Traffic Class Configuration
User Priority Traffic Class
------------- -------------
Priority 0: [ Low ]
Priority 1: [ Low ]
Priority 2: [ Low ]
Priority 3: [ Low ]
Priority 4: [ Low ]
Priority 5: [ Low ]
Priority 6: [ Low ]
Priority 7: [ Low ]
Changing the priorities of the traffic classes will cause an automatic
Reset to Current Settings to occur across the entire stack.
The current configuration will be adapted to the new set of priorities
Are you sure you want to change priorities to the new settings? [ No ]
Use space bar to display choices, press or to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
