NN42020-310 MCS 5100 3.5 Standard 1.0 June 2006
62 Copyright © Nortel Networks Limited 2006
• Machine Logical IP address of the CAM server
• BPS stack IP address
• Other optional devices (PRI Gateway host)
Provide between two and six ping targets or each IPMP group
for proper IPMP failover reliability. Enter the address "0.0.0.0" to
indicate list is complete, if entering less than six targets.
Note: Do NOT use this server's own IP address as a ping
target.
12 Press Enter after each IP address, for example: 0.0.0.0
[Enter]
(This is the third ping target machine logical IP
address.).
Example
Enter ping target #1:
120.120.13.22[Enter]
Enter ping target #2: 120.120.13.1[Enter]
Enter ping target #3: 0.0.0.0 [Enter]
Note: 0.0.0.0 ends the ping target list.
13 You will see the configuration summary appear as shown in the
following figure:
Figure 17 Application server IPMP configuration summary
