MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide
27 Copyright © Nortel Networks Limited 2006
Setting up rack to mount hardware
Procedure 1 Setting up rack to mount hardware
At the rack,
1 Mount all equipment. Refer to the following diagram that displays
the mounting for the rack.
• Mount Layer-2 switch.
• Mount the MRV LX terminal server.
• Mount Sun Fire V210s.
— Database/Management/Accounting server
— Application server
• (optional equipment) Mount conference server. Refer to the
Media Application Server documentation for more
information.
• (optional equipment) Mount gateway. Refer to
customer-specific gateway installation documentation.
Note: All MCS equipment is 19-inch rack mountable.
ATTENTION
Make sure you have
•
Business Policy Switch 2000 (BPS 2000) or Layer-2 switch
• vendor documentation for configuring your Layer-2 switch
• one (1) additional cat-5 ethernet cable to connect the MRV LX
terminal server to the layer-2 switch
• a pc for the System Management Console, and access to the
network
WARNING
Static electricity could be harmful to the servers.
