MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide
137 Copyright © Nortel Networks Limited 2006
The shaded rows indicate values that must be addressed by the
installer.
3 Use the values from the table that follows to complete the Web
Client Manager tab parameters.
The shaded rows indicate values that must be addressed by the
installer.
Table 32 SIP TCF Base tab
Parameter
Recommended
Value
Notes Example
Transport Config UDP=logical IP of the WCM
Server.>:5080:optiona
l;TCP=logical IP of the WCM
Server.>:5080:optiona
l;UDP=logical IP of the WCM
Server.>:5085:optiona
l:name=sipLscConduit
;TCP=logical IP of the WCM
Server.>:5085:optiona
l:name=sipLscConduit Replace
each
instance of
0.0.0.0 in the
UDP and
TCF strings
with the
machine
logical IP
address of
the Web
Client
Manager
Server UDP=120.120.13.25:
5080:optional;TCP=1
20.120.13.25:5080:o
ptional;UDP=120.12
0.13.25:5085:optiona
l:name=sipLscCondu
it;TCP=120.120.13.2
5:5085:optional:nam
e=sipLscConduit
Invite Timer 128000 default
Maximum Number
of Redirections 5 default
Initial Maximum
Hop Value 20 default
Table 33 Web Client Manager tab (Sheet 1 of 2)
Parameter
Recommended
value
Notes Example
WCM Socket Server Active checked checked
WCM Socket Server Host address of the Web
Client Manager> 120.120.12.43
WCM Socket Server Port 3090 default
