MCS 2-server Sun Fire V210 (RoHS) Solaris Installation and Commissioning Guide
113 Copyright © Nortel Networks Limited 2006
The shaded rows indicate values that must be addressed by the
installer.
6 Use the values from the table that follows to complete the SIP
TCF Base tab parameters.
7 Use the values from the following table to complete the In
Memory Database tab parameters.
Table 6 Database Base tab
Parameter Recommended value Notes Example
Primary Host database server> 120.120.13.22
Connections 8 default
Secondary Host Not applicable
Table 7 SIP TCF Base tab
Parameter Recommended value Notes Example
Transport Config UDP=IP of application server>
:5060:optional:name=sip
LscConduit;TCP=
application server>:5060
:optional:name=sipLscC
onduit This is
the IP
address
of the
App svr UDP=120.120
.13.25:5060:
optional:name
=sipLscCondu
it;TCP=120.12
0.13.25:5060:
optional:name
=sipLscCondu
it
Invite Timer 128000 default
Maximum Number of
Redirections 5 default
Initial Maximum Hop Value 20 default
