NN42020-310 MCS 5100 3.5 Standard 1.0 June 2006
130 Copyright © Nortel Networks Limited 2006
Procedure 36 Configuring the Provisioning Module tabs
At the System Management Console,
1 Use the values from the table that follows to complete the SIP
TCF Base tab parameters.
The shaded rows indicate values that must be addressed by the
installer.
2 Use the values from the table that follows to complete the User
Agent Server tab parameters.
The shaded rows indicate values that must be addressed by the
installer.
Table 24 SIP TCF Base tab
Parameter Recommended value Notes Example
Transport Config UDP=logical IP of IPCM
Server>:5070:optional
;TCP=logical IP of IPCM
Server>:5070:optional Replace each
instance of
0.0.0.0 in the
UDP and TCP
string with the
machine logical
IP address of the
IPCM server UDP=120.120.
13.25:5070:opt
ional;TCP=120
.120.13.25:507
0:optional
Invite Timer 128000 default
Maximum Number of
Redirections 5 default
Initial Maximum Hop
Value 20 default
Table 25 User Agent Server tab
Parameter Recommended value Notes Example
Application Server
Host IP address of the
application server> 120.120.13.25
Application Server
Port 5060 default
Click-to-call
Cancel Delay 18 default
